Chapter 4 217
Assembly Replacement
Front Frame Subassemblies
Figure 4-31 Front Frame Subassemblies
The front frame assembly consists of the following sub-assemblies:
Item Description
1 Display Shield Borad
2 Front Panel Interface Board
3Inverter Boards
4 Display Ribbon Cable
5 Backlight Extension Cables
6 Backlight Connectors
