88 Chapter 2
Block Diagrams
Mnemonics and Connectors
FLOPPY_DS3L Drive select #3 signal from the floppy controller chip on the CPU board to the floppy drive
FLOPPY_HSL Head select signal from the floppy controller chip on the CPU board to the floppy drive
FLOPPY_IDXL Index signal from the floppy drive to the floppy controller chip on the CPU board
FLOPPY_MID
FLOPPY_RDDL Read disk data from the floppy drive to the floppy controller chip on the CPU board
FLOPPY_READY
FLOPPY_STEPL Step pulse signal from the floppy controller chip on the CPU board to the floppy drive
FLOPPY_TR00L Track 00 status signal from the floppy drive to the floppy controller chip on the CPU board
FLOPPY_WDL Write data signal from the floppy controller chip on the CPU board to the floppy drive
FLOPPY_WEL Write enable signal from the floppy controller chip on the CPU board to the floppy drive
FLOPPY_WPL Write protect signal from the floppy drive to the floppy controller chip on the CPU board
FP_A0 Front panel bus address 0 (LSB) signal from the CPU board to the front panel interface board
FP_A1 Front panel bus address 1 signal from the CPU board to the front panel interface board
FP_A2 Front panel bus address 2 signal from the CPU board to the front panel interface board
FP_A3 Front panel bus address 3 signal from the CPU board to the front panel interface board
FP_BLUE0 Flat panel display blue 0 (LSB) signal from the CPU board to the front panel interface board
FP_BLUE1 Flat panel display blue 1 signal from the CPU board to the front panel interface board
FP_BLUE2 Flat panel display blue 2 signal from the CPU board to the front panel interface board
FP_BLUE3 Flat panel display blue 3 (MSB) signal from the CPU board to the front panel interface board
FP_CBLANKL Flat panel display blanking signal from the CPU board to the front panel interface board
FP_CLK Front panel bus 7.5 MHz clock signal from the CPU board to the front panel interface board
FP_CSL Front panel bus chip select signal from the CPU board to the front panel interface board
FP_D0 Front panel bus data 0 (LSB) signal from the CPU board to the front panel interface board
FP_D1 Front panel bus data 1 signal from the CPU board to the front panel interface board
FP_D2 Front panel bus data 2 signal from the CPU board to the front panel interface board
FP_D3 Front panel bus data 3 signal from the CPU board to the front panel interface board
FP_D4 Front panel bus data 4 signal from the CPU board to the front panel interface board
FP_D5 Front panel bus data 5 signal from the CPU board to the front panel interface board
FP_D6 Front panel bus data 6 signal from the CPU board to the front panel interface board
FP_D7 Front panel bus data 7 (MSB) signal from the CPU board to the front panel interface board
FP_DOTCLK Flat panel display 25 MHz dot clock signal from the CPU board to the front panel interface board
FP_GREEN0 Flat panel display green 0 (LSB) signal from the CPU board to the front panel interface board
FP_GREEN1 Flat panel display green 1 signal from the CPU board to the front panel interface board
Table 2-1 Mnemonic Descriptions
Mnemonic Description
