Preparing for Initial Use of Your New FieldFox 11
Install the Lithium-Ion Battery
1. Open the battery door.
Push the button on the battery compartment door while sliding the door outward.
The terminals end of the battery is inserted into the compartment.
3. Close the battery door.
Slide the battery compartment door upwards until it latches.
Battery Usage
When you receive your FieldFox, the lithium-ion battery is not installed, and it is
partially charged to approximately 40% to preserve battery life. A lithium-ion
battery has no memory effect, so it can be used partially charged, as shipped.
A fully charged battery will power your FieldFox for about four hours, so if you
plan to use it for this long, you should fully charge the battery.
NOTE The FieldFox will shut down to prevent the battery from discharging to a level
that is damaging. If this occurs, charge the battery either internally or externally.
Learn more about the lithium-ion battery on page 188.
Battery charge status is viewable:
In the upper-right corner of the screen.
On the Battery screen. To access the screen, select System, Service
Diagnostics, and Battery.
On the battery. Open the FieldFox battery compartment door to view the
battery LCD.
To conserve battery power:
Use Run/Hold to single-trigger a measurement when needed. Hold is shown on
the display.
Press System then Display then Brightness. Use the ▲|▼ arrows, the rotary
knob, or numeric keypad to adjust the brightness to dim the FieldFox display
as much as possible.
Briefly press the power button to switch to Stand By mode when the FieldFox
is not being used. Press again to restore power. All current settings are
preserved.
