Interference Analyzer (SA Mode) Option 236 123
o Playback Trace Activated automatically when Paused. Allows you to
continue playback from a specific trace, or scroll through traces manually.
Enter a value between 1 and the total number of traces using the numeric
keypad, ▲|▼ arrows, or the rotary knob.
Stop Immediately stops playback. Then choose from the following:
o Play Start playback from trace 1.
o Record Resume recording from the last recorded trace.
o Record Playback Setup Return to the setup menu to change Configuration
settings or Close the session.
Recording Configuration
To change Recording Configuration settings:
Press Trace 6
Then Record Playback Setup
Then New Session or Recall an existing session.
Then Recording Configuration
Then choose from the following:
o Record Time Sets the amount of time to record traces. Default is MAX,
which is to record indefinitely. Enter a value between 1s and 1 Ms (million)
seconds using the numeric keypad, ▲|▼ arrows, or the rotary knob. When
set, a timer appears during recording in the lower-left corner which counts
DOWN from the specified time.
o Record Source Sets where, in the FieldFox data flow, data is recorded.
Learn more about Record Source on page 124.
Choose from the following:
o RawMeas Records raw measurement data.
o Trace 1,2,3,4 Records data from the corresponding trace in its current state.
o Record Interval Sets the amount of time to wait between individual trace
recordings. Default is MIN, which is to wait 0 seconds (record traces as fast
as possible). Enter a value in seconds between 0 (no delay) and 10,000
seconds - about 3 hrs) using the numeric keypad, ▲|▼ arrows, or the rotary
knob.
o Segment Count Sets the number of traces to record, after which the
recording will automatically pause. Press Pause/Resume or Record to
capture another N traces, or Stop to end recording. Default is OFF, which is
NO limit to the number of traces to be recorded. When set, a counter appears
in the lower-left corner which counts UP to the specified number of
recordings.
o FreqMaskTrigger OFF ON Sets the power level which will trigger a
recording. Set these power levels (mask) exactly as you would set Limit
Lines. (Learn how on page 158.) With Record ON, when any data point
measurement is higher than an upper limit, or lower than a lower limit,
recording begins. See Frequency Mask Trigger Configuration in the following
section to learn how to configure the mask.
