Agilent Technologies FieldFox N9913A User Manual

NA (Network Analyzer) Mode 47
How to set Smoothing
 Press BW 2.
 Then Smoothing ON OFF
 Then Sm. Aperture and enter a value between 0 and 25 (percent) using the
numeric keypad.
 Press Enter
Single or Continuous Measure
This setting determines whether the FieldFox sweeps continuously or only once
each time the Single button is pressed. Use Single to conserve battery power or
to allow you to save or analyze a specific measurement trace.
This setting can be changed at any time without affecting calibration accuracy.
How to set Single or Continuous
 Press Sweep 3.
 Then choose one of the following:
o Single Automatically sets Continuous OFF and causes FieldFox to make
ONE sweep, then hold for the next Single key press. Hold is annotated in
the upper left corner of the display when NOT sweeping, and changes to an
arrow --> while the sweep occurs.
o Continuous Makes continuous sweeps. This is the typical setting when
battery power is not critical.
You can also use Run / Hold +/- to toggle between Single and Continuous.
Resolution (Number of Data Points)
Data points are individual measurements that are made and plotted across the X-
axis to form a trace. Select more data points to increase measurement resolution.
However, more data points also takes more time to complete an entire
measurement sweep.
When the Resolution is changed after a calibration is performed, the cal becomes
interpolated. Learn more on page 71.
How to set Resolution
 Press Sweep 3.
 Then Resolution.
 Then choose from the following:
101 |201 | 401 | 601 | 801 | 1001 | 1601 | 4001 | 10001.
 Using SCPI, Resolution can be set to ANY number of points between 3 and
10001. See the Programming Guide at http://na.tm.agilent.com/fieldfox/help/
