58 FieldFox User’s Guide
With compensation for the loss using the manufacturer’s specification, the
FieldFox compensates the trace as though the signal traveling through 100
meters was increased by +20 dB. Therefore the response will show 0 dB for 100%
reflection.
Data Chain
This setting, available only on the Transform Settings Table, reverts to Standard
when the FieldFox is Preset. Choose from the following:
 Standard – The normal FieldFox data processing chain. Transform
calculations are performed AFTER error correction and trace math.
 8510 – The data processing chain used by the Agilent 8510 network analyzer.
Transform calculations are performed BEFORE error correction and trace
math. Learn more at the FieldFox Supplemental Online Help website:
http://na.tm.agilent.com/fieldfox/help/FieldFox.htm
Trace Settings
The following two settings apply to specific traces.
Transform Enable
Enable Time Domain transform for the specific trace.
 Select the trace.
 Press Measure 4
 Then Transform
 Then choose from:
o On Trace displays Time Domain data.
o Off Trace displays frequency domain data.
Gate Enable
Enable Gating for the specific trace.
 Select the trace.
 Press Measure 4
 Then Transform
 Then choose from:
o On Trace displays Time Domain data.
o Off Trace displays frequency domain data.
