Agilent Technologies FieldFox N9913A - Na (Network Analyzer) Mode; NA Mode Settings

38 FieldFox User’s Guide
NA (Network Analyzer) Mode
Learn more about NA Mode measurements in the FieldFox Supplemental Online
Help: http://na.tm.agilent.com/fieldfox/help/FieldFox.htm
In this Chapter
How to Measure S-parameters ............................ 39
Receiver Measurements ........................................ 40
Multi-Trace Configurations .................................. 40
Quick Settings ........................................................ 42
Format ..................................................................... 42
Frequency Range ................................................... 43
Scale Settings ......................................................... 44
Electrical Delay ...................................................... 44
Phase Offset ............................................................ 45
Averaging ................................................................ 45
IF Bandwidth .......................................................... 46
Smoothing ............................................................... 46
Single/Continuous ................................................. 46
Resolution (number of points) ............................ 47
Sweep Time ............................................................. 48
Output Power ......................................................... 48
System Impedance ................................................. 49
Port Extensions ...................................................... 50
Velocity Factor ....................................................... 51
Increase Dynamic Range ...................................... 51
See Also
All about Calibration ............................................. 53
Set Markers ........................................................... 148
Use Limit Lines .................................................... 158
Use Trace Math .................................................... 161
Learn how to make 75Ω (ohm) Measurements in the Supplemental Online Help:
http://na.tm.agilent.com/fieldfox/help/FieldFox.htm
NA Mode Settings
Select NA Mode before making any setting in this section.
How to select NA Mode
 Press Mode_.
 Then NA.
