Interference Analyzer (SA Mode) Option 236 121
Record/Playback Exceptions
 Markers can be activated and moved to help analyze recorded data. However,
marker position control is only available when playback is Paused.
 Field Strength Corrections is saved with the session file and it is also allowed
during playback. Learn about this Field Strength Corrections on page 83.
 Frequency Counter at Marker is NOT allowed during Recording or Playback.
Learn about this feature on page 105.
About State and User Tags
When any of the State settings (listed above) are changed during a recording, a
‘state tag’ is inserted at the first trace number to be recorded with the new
setting.
In addition, you can insert a ‘User Tag’ at any time during a recording session to
indicate an external event, such as when an antenna is moved. During playback,
you can move quickly to any of these tags, or scroll through these tags.
A symbol is used on the screen annotation to distinguish a User Tag from a State
Tag when scrolling through tags during playback.
Screen Annotation
During a record or playback session, the following is displayed in the top-left
area of the screen:
 AutoSession02: 92/95 (state 4/5)_*_
Sep.22.2009 09:15:15 AM
where:
 AutoSession is an auto-generated name for sessions. 02 is the auto-generated
number, incremented with each new session. The name can be changed using
Manage Sessions. Learn more on page 125.
 92/95 is the current and total trace number: currently trace is 92 of 95 total
traces.
 state 4/5 is the current and total state tag or user tag number: 4 of 5 total tags.
 * (Asterisk) indicates that a state has changed. # (Pound) indicates that a User
Tag has been inserted.
 Sep.22... is the date and time of recording.
When GPS is enabled and displayed, the current location and elevation are
annotated at the bottom of the playback display. Learn more about GPS on page
179.
NOTE If Recording or Playback is not occurring when you think it should, check the
following:
 Is the sweep in HOLD ? (upper-left annotation)
 Is Recording or Playback Paused ? (mid-left annotation)
 Is the Record or Playback Interval set to a long delay? (Configuration settings.)
