Transport, siting and installation
Fig. 5-31 Bracket on the bottom carriage
Fig. 5-32 Position of e-chain
[1] Place the bottom e-chain on the bracket on the bottom carriage.
[2] Run the cable into the machine frame through the opening in the bottom carriage.
