MM-400A
8. Operation Screens
8-67
(Reference) TRIGGER setting and measurement
Measurement start item varies depending on the TRIGGER setting.
TRIGGER setting and measurement start item
Measurement start item
CURRENT
*1
VOLTAGE
DISPLACEMENT
FORCE
*1
EXTERNAL
*1
DISPLACEMENT
*2
(E
XTERNAL INPUT
)
FORCE
*2
(
EXTERNAL INPUT
)
EXTERNAL
*2
(
EXTERNAL INPUT
)
TRIGGER setting
CURRENT ○ × × × × × × ×
AUTO ○ × × ○ ○ × ○ ○
FORCE × × × ○ × × × ×
EXTERNAL × × × × ○ × × ×
DISPLACEMENT (EXT) × × × × × ○ × ×
FORCE (EXT) × × × × × × ○ ×
EXTERNAL (EXT) × × × × × × × ○
*1: Measurement starts when the set threshold is exceeded.
*2: Measurement starts when IN7/IN8 (specified by setting) of the external input is
closed.
TRIGGER setting and measurement item
Measurement item
CURRENT
VOLTAGE
POWER
RESIST
DISPLACEMENT
FORCE
EXTERNAL
TRIGGER setting
CURRENT
*3
○ ○ ○ ○ ○ × ×
AUTO
*4 *5
○ ○ ○ ○ ○ ○ ○
FORCE
*6
○ ○ ○ ○ ○ ○ ○
EXTERNAL
*7
○ ○ ○ ○ ○ ○ ○
DISPLACEMENT (EXT)
*8
○ ○ ○ ○ ○ × ×
FORCE (EXT)
*9
○ ○ ○ ○ ○ ○ ○
EXTERNAL (EXT)
*10
○ ○ ○ ○ ○ ○ ○
*3: Measurement of CURRENT/VOLTAGE/POWER/RESIST/DISPLACEMENT is
performed when current measurement starts.
*4: Measurement of
CURRENT/VOLTAGE/POWER/RESIST/DISPLACEMENT/FORCE/EXTERNAL
is performed when current measurement starts.
