MM-400A
9. Measurement
9-21
22) When the trigger signal is input to the MM-400A, the [TRIGGER] lamp lights
up and measurement starts. Confirm the measurement results on the
MEASUREMENT and WAVEFORM screens. You can also print measured
values and waveforms from the PRINT screen, as necessary.
A
WE1 CO1 WE2 CO2 WE3
Force
Welding current
Built-in
load cell
Judgment output
External input signal
"MEAS BEFORE WELD"
(Output before welding)
