MM-400A
12. Data Communication
12-10
Item
Display
example
Range Length
72 MEAS 8 Refer to the measurement code table (Measured
value).
1 to 7
73 Unit 8 Refer to the measurement code table (Unit). 0 to 4
74 Delimiter , 1
75 Measurement item code 9 Refer to the measurement code table (Item code). 2
76 Delimiter , 1
77 Judgment 9 Refer to the judgment code table (Code). 1
78 Delimiter , 1
79 MEAS 9 Refer to the measurement code table (Measured
value).
1 to 7
80 Unit 9 Refer to the measurement code table (Unit). 0 to 4
81 Delimiter , 1
82 Measurement item code
10
Refer to the measurement code table (Item code). 2
83 Delimiter , 1
84 Judgment 10 Refer to the judgment code table (Code). 1
85 Delimiter , 1
86 MEAS 10 Refer to the measurement code table (Measured
value).
1 to 7
87 Unit 10 Refer to the measurement code table (Unit). 0 to 4
88 Delimiter , 1
89 ENVELOPE#1 Waveform
item code
Refer to the waveform code table (Item code). 1
90 Delimiter , 1
91 ENVELOPE#1
SEGMENT#1 Judgment
Refer to the judgment code table. 1
92 Delimiter , 1
93 ENVELOPE#1
SEGMENT#2 Judgment
Refer to the judgment code table. 1
94 Delimiter , 1
95 ENVELOPE#1
SEGMENT#3 Judgment
Refer to the judgment code table. 1
96 Delimiter , 1
97 ENVELOPE#2 Waveform
item code
Refer to the waveform code table (Item code). 1
98 Delimiter , 1
99 ENVELOPE#2
SEGMENT#1 Judgment
Refer to the judgment code table. 1
100 Delimiter , 1
101 ENVELOPE#2
SEGMENT#2 Judgment
Refer to the judgment code table. 1
102 Delimiter , 1
