MM-400A
12. Data Communication
12-11
Item
Display
example
Range Length
103 ENVELOPE#2
SEGMENT#3 Judgment
Refer to the judgment code table. 1
104 Return code [CR] (0x0d) 1
105 Feed code [LF] (0x0a) 1
Communication example
Measurement data (without unit, decimal point is period) of ID NO. 01 and SCH.# 1 is
transmitted from the MM-400A.
“MM-400A → Host computer”
!01001S01:17/12/31_23:59:59,02,G,01.00,00,G,01.10,05,G,02.0,03,G,02.2,09,G,0300.0,06,
-,060,07,G,080.00,08,G,100.00,16,G,+01.000,18,G,20.00,0,G,G,-,1,G,G,-[CR][LF]
(Note) A space falls into “_”.
