MM-400A
12. Data Communication
12-12
2) WAVEFORM
Data is transmitted in the order of i), ii) and iii).
i) Measurement data part
Item
Display
example
Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 02 2
6 Delimiter : 1
7 “Year” to 103 “ENVELOPE#2 SEGMENT#3 Judgment” in 1) MEASUREMENT
104 Return code [CR] (0x0d) 1
105 Feed code [LF] (0x0a) 1
ii) Item code part
Item
Display
example
Range Length
1 Waveform item code 1 Refer to the waveform code table (Item code). 0 to 1
2 Delimiter , 0 to 1
3 Waveform item code 2 Refer to the waveform code table (Item code). 0 to 1
4 Delimiter , 0 to 1
5 Waveform item code 3 Refer to the waveform code table (Item code). 0 to 1
6 Delimiter , 0 to 1
7 Waveform item code 4 Refer to the waveform code table (Item code). 0 to 1
8 Return code [CR] (0x0d) 1
9 Feed code [LF] (0x0a) 1
(Note) Omitted when ITEM is not set.
iii) Waveform data part
Item
Display
example
Range Length
1 TIME 00000.00 00000.00 to 10000.00 8
2 Unit of TIME ms 2
3 Delimiter , 1
4 MEAS 1 Refer to the waveform code table (Measured value). 0 to 7
5 Unit 1 Refer to the waveform code table (Unit). 0 to 4
6 Delimiter , 0 to 1
7 MEAS 2 Refer to the waveform code table (Measured value). 0 to 7
8 Unit 2 Refer to the waveform code table (Unit). 0 to 4
9 Delimiter , 0 to 1
10 MEAS 3 Refer to the waveform code table (Measured value). 0 to 7
