MM-400A
12. Data Communication
12-13
Item Display
example
Range Length
11 Unit 3 Refer to the waveform code table (Unit). 0 to 4
12 Delimiter , 0 to 1
13 MEAS 4 Refer to the waveform code table (Measured value). 0 to 7
14 Unit 4 Refer to the waveform code table (Unit). 0 to 4
15 Return code [CR] (0x0d) 1
16 Feed code [LF] (0x0a) 1
1 to 16 are output by the number of waveform data.
17 End of transmission [EOT] (0x04) 1
Communication example
Measurement, item and waveform data (without unit, decimal point is period, waveform
output: current, voltage, power, and resistance) of ID NO .01 and SCH.# 1 is transmitted
from the MM-400A.
“MM-400A → Host computer”
!01001S01:17/12/31_23:59:59,02,G,01.00,00,
G,01.10,05,G,02.0,03,G,02.2,09,0300.0,06,
060,07,G,080.00,08,G,100.00,16,G,+01.000,
18,G,00020.00,0,G,G,-,1,G,G,-[CR][LF]
0,1,2,3[CR][LF]
00000.00,00.00,00.0,000.00,000.00[CR][LF]
00000.02,00.20,00.2,000.04,001.00[CR][LF]
.
.
.
00010.00,00.20,02.2,010.04,001.00[CR][LF][EOT]
