MM-400A
12. Data Communication
12-14
3) CURR ALL CYCLE
Data is transmitted in the order of i) and ii).
i) Measurement data part
Item
Display
Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 03 2
6 Delimiter : 1
7 “Year” to 103 “ENVELOPE#2 SEGMENT#3 Judgment” in 1) MEASUREMENT
104 Return code [CR] (0x0d) 1
105 Feed code [LF] (0x0a) 1
ii) All cycle data part
Item
Display
Range Length
1 TIME 0000.0
0000
0000.0 to 2000.0 (0.5-CYC increment)
0000 to 5000 (1-ms increment)
6
4
2 Unit of TIME CYC
ms
3
2
3 Delimiter , 1
4 Measurement range *
_
*: Within measurement range
_: Outside of measurement range
1
5 Delimiter , 1
6 CURRENT 0.000
00.00
000.0
0.000 to 9.999
00.00 to 99.99
000.0 to 999.9
5
7 Unit of CURRENT kA 2
8 Delimiter , 1
9 VOLTAGE 0.00
00.0
0.00 to 9.99
00.0 to 99.9
4
10 Unit of VOLTAGE V 1
11 Delimiter , 0 to 1
12 ANGLE 000 000 to 180 0 to 3
13 Unit of ANGLE deg 0 to 3
14 Return code [CR] (0x0d) 1
15 Feed code [LF] (0x0a) 1
1 to 15 are output by the number of all cycle data. ANGLE is not occasionally output. In that
case, 11 Delimiter, 12 ANGLE and 13 Unit of ANGLE are not output.
16 End of transmission [EOT] (0x04) 1
