MM-400A
12. Data Communication
12-15
Communication example
Measurement (with unit, decimal point is period) of ID NO. 01 and SCH. #1 and current all
cycle data (start 3 CYC) are transmitted from the MM-400A.
“MM-400A → Host computer”
!01001S03:01/17_04:24:31,02,G,01.20kA,00,
G,01.76kA,05,G,00.0V,03,G,00.0V,09,G,
0008.0CYC,19,G,0812N,34,-,0,34,-,0,34,-,
0,34,-,0,0,G,G,-,1,G,G,-[CR] [LF]
0000.5CYC, ,01.42kA,00.0V,180deg[CR][LF]
0001.0CYC, ,01.47kA,00.0V,180deg[CR][LF]
0001.5CYC, ,01.47kA,00.0V,180deg[CR][LF]
0002.0CYC, ,01.46kA,00.0V,180deg[CR][LF]
0002.5CYC, ,01.42kA,00.0V,180deg[CR][LF]
0003.0CYC,*,01.45kA,00.0V,180deg[CR][LF]
0003.5CYC,*,01.46kA,00.0V,180deg[CR][LF]
0004.0CYC,*,01.49kA,00.0V,180deg[CR][LF]
.
.
.
0008.0CYC,*,01.48kA,00.0V,180deg[CR][LF][EOT]
(Note) A space falls into “_”.
ii) Current all cycle data part
