MM-400A
12. Data Communication
12-16
4) FORCE ALL CYCLE
Data is transmitted in the order of i) and ii).
i) Measurement data part
Item
Display
example
Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 04 2
6 Delimiter : 1
7 “Year” to 103 “ENVELOPE#2 SEGMENT#3 Judgment” in 1) MEASUREMENT
104 Return code [CR] (0x0d) 1
105 Feed code [LF] (0x0a) 1
ii) All cycle data part
Item
Display
example
Range Length
1 TIME 00000 00000 to 10000 5
2 Unit of TIME ms 2
3 Delimiter , 1
4 Measurement range
of FORCE
*
_
*: Within measurement range
_: Outside of measurement range
1
5 Delimiter , 1
6 FORCE 00.00
000.0
00000
00.00 to 99.99
000.0 to 999.9
00000 to 09999
5
7 Unit of FORCE N
kgf
lbf
1
3
3
8 Delimiter , 1
9 Measurement range
of EXTERNAL
*
_
*: Within measurement range
_: Outside of measurement range
1
10 Delimiter , 1
11 EXTERNAL +0.000
+00.00
+000.0
+00000
-9.999 to +9.999
-99.99 to +99.99
-999.9 to +999.9
-09999 to +09999
6
