Amada WELD CHECKER MM-400A - Page 238

MM-400A
12. Data Communication
12-17
Item
Display
example
Range Length
12 Unit of EXTERNAL
V
N
kgf
lbf
degC
degF
Mpa
bar
psi
0
1
1
3
3
4
4
3
3
3
13 Return code [CR] (0x0d) 1
14 Feed code [LF] (0x0a) 1
1 to 14 are output by the number of all cycle data.
15 End of transmission [EOT] (0x04) 1
Communication example
Measurement of ID NO. 03 and SCH.# 2 and force all cycle data (start 0 CYC) is transmitted
from the MM-400A.
“MM-400A → Host computer”
!03002S01:17/09/09_03:04:05,02,G,00.00kA,
00,G,01.76kA,05,G,00.0V,03,G,00.0V,09,G,
0008.0CYC,19,G,0812N,34,-,0,34,-,0,34,-,
0,34,-,0,0,G,G,-,1,G,G,-[CR][LF]
00010ms,*,0812N,-0056[CR][LF]
00020ms,*,0812N,+0077[CR][LF]
00030ms,*,0812N,-0028[CR][LF]
00040ms,*,0811N,-0061[CR][LF]
.
.
.
00170ms,*,0812N,-0012[CR][LF][EOT]
(Note) A space falls into “_”.
ii) Force all cycle data part
i) Measurement data part
