MM-400A
12. Data Communication
12-18
5) HISTORY
Item
Display
example
Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 06 2
6 Delimiter : 1
7 “Year” to 103 “ENVELOPE#2 SEGMENT#3 Judgment” in 1) MEASUREMENT
104 Return code [CR] (0x0d) 1
105 Feed code [LF] (0x0a) 1
Data transmission of 1 to 105 is repeated by the number of measurement histories (including
the judgment error).
106 End of transimission [EOT] (0x04) 1
6) HISTORY OUT OF LIM
Item
Display
example
Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 07 2
6 Delimiter : 1
7 “Year” to 103 “ENVELOPE#2 SEGMENT#3 Judgment” in 1) MEASUREMENT
104 Return code [CR] (0x0d) 1
105 Feed code [LF] (0x0a) 1
Data transmission of 1 to 105 is repeated by the number of error histories.
106 End of transimission [EOT] (0x04) 1
If there is no error history, data transmission is not performed.
