MM-400A
12. Data Communication
12-21
Communication example
!01000S11:0,02,00,05,03,09,34,34,34,34,34,0,1,2,3,1,1,0,0[CR][LF]
!01000S12:90,0,0,0,0[CR][LF]
!01001S12:ay001,0,1,050,0,0,000000ms,002000ms,0,00,0.000kA,00001m
s,80%,0005ms,00.0s,05.0%[CR][LF]
...
!01127S12:ay127,0,0,050,2,1,0000.0CYC,0300.0CYC,0,00,00.00kA,000.5
CYC,80%,01.0CYC,00.0s,05.0%[CR][LF]
!01000S13:0,0,0,0,0,0,01.0um,1,0,2,2,1000,1.000mV/V,09806N,0,0,10.0%
,0,0,09999,0,0,10.0%,0,+00000N[CR][LF]
!01001S13:+00.000mm,+00.000mm,+00.000mm,00000ms,0000ms,0000m
s,0000ms,00000N,00000N,00000N,0000ms...[CR][LF]
...
!01127S13:+00.000mm,+00.000mm,+00.000mm,00000ms,0000ms,0000m
s,0000ms,00000N,00000N,00000N,0000ms...[CR][LF]
!01000S14:0,4,000000,000000,07,0,2,227.0mV/kA,0[CR][LF]
!01000S15:0,0,2,2,1,90,90,0,05.0%[CR][LF]
!01001S15:ay001,000.0CYC,0.5CYC,00.5CYC,00000.0CYC,18000.0CYC,
00000.0CYC,18000.0CYC,00000.0CYC,18000.0CYC,99.99kA...[CR][LF]
...
!01127S15:ay127,000.0CYC,0.5CYC,00.5CYC,00000.0CYC,18000.0CYC,
00000.0CYC,18000.0CYC,00000.0CYC,18000.0CYC...[CR][LF]
!01001S16:009.999kA,000.000kA,009.999kA,000.000kA,0009.99V,0000.0
0V,0009.99V,0000.00V,0030000ms, ...[CR][LF]
...
!01127S16:0099.99kA,0000.00kA,0099.99kA,0000.00kA,00099.9V,00000.
0V,00099.9V,00000.0V,03000.0CYC, ...[CR][LF]
!01000S17:1,3[CR][LF]
!01001S17:+000.000kA,+000.000kA,+000.000kA,+0000.00V,+0000.00V,+
0000.00V,+000.000kA,+000.000kA, ...[CR][LF]
...
!01020S17:+0000.00kA,+0000.00kA,+0000.00kA,+0000.00kA,+0000.00kA
,+0000.00kA,+0000.00kA,+0000.00kA, ...[CR][LF]
!01000S18:0,1,2,3,4,8,0,1,00,62,62,01,62,62, ...[CR][LF]
!01000S21:0,0001,0[CR][LF]
!01000S22:7,0001,0,3,0,0,2,0,01,0,192 168 001 010,255 255 255 000,192
168 001 100,1024[CR][LF]
!01000S23:9,0001,0,2,0,0[CR][LF]
!01000S24:0,0001,0,3[CR][LF]
b)
c)
d)
f)
g)
e)
h)
i)
j)
k)
l)
a)
