MM-400A
12. Data Communication
12-24
• Writing request and output data
1) BASIC SETUP [Item No. 12]
Writing request data for each schedule 001 to 127
Item Display Range Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 001 001 to 127 3
5 Screen code S 1
6 Item No. 12 2
7 Delimiter : 1
8 SCHEDULE NAME ABCDE A to Z, 0 to 9 5
9 Delimiter , 1
10 TRIGGER 0 0: CURRENT 1: AUTO 2: FORCE
3: EXTERNAL 4: REAL TIME
5: DISPLACEMENT (EXT) 6: FORCE (EXT)
7: EXTERNAL (EXT)
1
11 Delimiter , 1
12 TIME 0 0: CYC-AC 1: ms-DC 2: CYC***Hz-AC
3: CYC-DC 4: ms-AC 5: SHORT ms-DC
6: LONG CYC-AC
1
13 Delimiter , 1
14 FREQUENCY 050 030 to 250
030:M050 031:M053 032:M056 033:M059
034:M063 035:M067 036:M071 037:M077
038:M083 039:M091 040:M100 041:M111
042:M125 043:M143 044:M167 045:M200
046:M250 047:M294 048:M417 049:M500
050 to 250:050 to 250Hz
3
15 Delimiter , 1
16 CURRENT RANGE 0 1x sensitivity coil
0: 2.000kA 1: 6.00kA 2: 20.00kA
3: 60.0kA 4: 200.0kA
10x sensitivity coil
0: 0.200kA 1: 0.600kA 2: 2.000kA
3: 6.00kA 4: 20.00kA
1
17 Delimiter , 1
18 VOLTAGE RANGE 0 0: 6.00V 1: 20.0V 1
19 Delimiter , 1
To Next Page
