MM-400A
12. Data Communication
12-25
Item Display Range Length
20 START TIME 0000.0CYC 0000.0 to 0300.0CYC (TIME CYC-AC, in 0.5
CYC steps)
0000.0 to 2000.0CYC (TIME CYC***Hz-AC
, in
0.5 CYC steps)
0000.0 to 0120.0CYC (TIME CYC-DC, in 0.5
CYC steps)
0000.0 to 0600.0CYC (TIME LONG CYC-AC,
in 0.5 CYC steps)
000000 to 002000ms (TIME ms-DC)
000000 to 005000ms (TIME ms-AC)
000.00 to 300.00ms (TIME SHORT ms-DC)
9
21 Delimiter , 1
22 END TIME 0000.0CYC 0000.0 to 0300.0CYC (TIME CYC-AC, in 0.5
CYC steps)
0000.0 to 2000.0CYC (TIME CYC***Hz-AC
, in
0.5 CYC steps)
0000.0 to 0120.0CYC (TIME CYC-DC, in 0.5
CYC steps)
0000.0 to 0600.0CYC (TIME LONG CYC-AC,
in 0.5 CYC steps)
000000 to 002000ms (TIME ms-DC)
000000 to 005000ms (TIME ms-AC)
000.00 to 300.00ms (TIME SHORT ms-DC)
9
23 Delimiter , 1
24 PULSE MODE 0 0: SET PULSE
1: ALL PULSE (SET)
2: ALL PULSE (NO SET)
3: NO COOL
4: ALL PULSE (SET2)
1
25 Delimiter , 1
26 PULSE NO. 00 00 to 20 2
27 Delimiter , 1
28 PULSE 2 TRIG
LEVEL
00.00kA 0.000 to 9.999kA (CURRENT RANGE 0.200,
0.600, 2.000kA)
00.00 to 99.99kA (CURRENT RANGE 6.00,
20.00kA)
000.0 to 999.9kA (CURRENT RANGE 60.0,
200.0kA)
7
29 Delimiter , 1
30 COOL TIME 000.5CYC 000.5 to 100.0CYC (in 0.5 CYC steps)
00001 to 02000ms_
000.1 to 200.0ms_
8
31 Delimiter , 1
32 FALL LEVEL 10% 10 to 90% 3
33 Delimiter , 1
34 MEASUREMENT
MIN TIME
000.5CYC 00.5 to 050.0CYC (in 0.5 CYC steps)
00001 to 01000ms_
000.1 to 100.0ms_
8
35 Delimiter , 1
