MM-400A
12. Data Communication
12-26
Item Display Range Length
36 MEAS INHIBIT TIME 00.0s 00.0 to 10.0s 5
37 Delimiter , 1
38 END LEVEL 01.5% 01.5 to 15.0% 5
39 Return code [CR] (0x0d) 1
40 Feed code [LF] (0x0a) 1
A space falls into “_” for digit matching.
 Output data for each schedule 001 to 127
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 12 2
6 Delimiter : 1
8 “SCHEDULE NAME” to 38 “END LEVEL” in BASIC SETUP  Writing request data for
schedule
38 Return code [CR] (0x0d) 1
39 Feed code [LF] (0x0a) 1
 Writing request data common to all schedules (SCH.# 000)
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 12 2
7 Delimiter : 1
8 CURRENT
TRIGGER LEVEL
01 01 to 99 2
9 Delimiter , 1
10 Toroidal coil 0 0: TIMES 1
1: TIMES 10
1
11 Delimiter , 1
12 CALCULATION 0 0: ORIGINAL
1: ISO17657
1
13 Delimiter , 1
14 CURRENT
SENSOR
0 0: TOROIDAL COIL
1: SHUNT RESISTOR
1
15 Delimiter , 1
