12. Data Communication
12-37
Item Display Range Length
52 Feed code [LF] (0x0a) 1
 Output data for each schedule 001 to 127
Item
Display
Range
Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 15 2
6 Delimiter : 1
8 “SCHEDULE NAME” to 50 “VOLTAGE LOWER 3” in SEAM SETUP  Writing request
data for schedule
50 Return code [CR] (0x0d) 1
51 Feed code [LF] (0x0a) 1
 Writing request data common to all schedules (SCH.# 000)
Item Display Range Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 15 2
7 Delimiter : 1
8 TRIGGER (Note) 0 0: CURRENT
1: VOLTAGE
1
9 Delimiter , 1
10 TIME (Note) 0 0: CYC-AC
1: ms-AC
2: ms-DC
3: CYC-DC
4: SHORT ms-DC
1
11 Delimiter , 1
12 CALCULATION 0 0: PEAK
1: RMS
2: AVERAGE RMS
1
13 Delimiter , 1
14 CURRENT RANGE 0 1x sensitivity coil
0: 2.000kA 1: 6.00kA 2: 20.00kA
3: 60.0kA 4: 200.0kA
10x sensitivity coil
0: 0.200kA
1: 0.600kA 2: 2.000kA
3: 6.00kA 4: 20.00kA
1
15 Delimiter , 1
