MM-400A
12. Data Communication
12-36
Item Display Range Length
26 TIME END 3 18000.0CYC 00000.0 to 18000.0CYC (in 0.5 CYC steps)
0000000 to 0300000ms_ (in 10 ms steps)
0000000 to 0030000ms_
10
*
27 Delimiter , 1
28 CURRENT UPPER
1
99.99kA 0.000 to 9.999kA
00.00 to 99.99kA
000.0 to 999.9kA
7
29 Delimiter , 1
30 CURRENT LOWER
1
00.00kA 0.000 to 9.999kA
00.00 to 99.99kA
000.0 to 999.9kA
7
31 Delimiter , 1
32 CURRENT UPPER
2
99.99kA 0.000 to 9.999kA
00.00 to 99.99kA
000.0 to 999.9kA
7
33 Delimiter , 1
34 CURRENT LOWER
2
00.00kA 0.000 to 9.999kA
00.00 to 99.99kA
000.0 to 999.9kA
7
35 Delimiter , 1
36 CURRENT UPPER
3
99.99kA 0.000 to 9.999kA
00.00 to 99.99kA
000.0 to 999.9kA
7
37 Delimiter , 1
38 CURRENT LOWER
3
00.00kA 0.000 to 9.999kA
00.00 to 99.99kA
000.0 to 999.9kA
7
39 Delimiter , 1
40 VOLTAGE UPPER
1
9.99V 0.00 to 9.99V
00.0 to 99.9V
5
41 Delimiter , 1
42 VOLTAGE LOWER
1
0.00V 0.00 to 9.99V
00.0 to 99.9V
5
43 Delimiter , 1
44 VOLTAGE UPPER
2
9.99V 0.00 to 9.99V
00.0 to 99.9V
5
45 Delimiter , 1
46 VOLTAGE LOWER
2
0.00V 0.00 to 9.99V
00.0 to 99.9V
5
47 Delimiter , 1
48 VOLTAGE UPPER
3
9.99V 0.00 to 9.99V
00.0 to 99.9V
5
49 Delimiter , 1
50 VOLTAGE LOWER
3
0.00V 0.00 to 9.99V
00.0 to 99.9V
5
51 Return code [CR] (0x0d) 1
