MM-400A
12. Data Communication
12-35
3) SEAM SETUP [Item No. 15]
 Writing request data for each schedule 001 to 127
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 001 001 to 127 3
5 Screen code S 1
6 Item No. 15 2
7 Delimiter : 1
8 SCHEDULE NAME ABCDE A to Z, 0 to 9 5
9 Delimiter , 1
10 START
MEASUREMENT
000.0CYC 000.0 to 120.0CYC (in 0.5 CYC steps)
00000 to 02000ms_ (in 10 ms steps)
00000 to 00200ms_
8
11 Delimiter , 1
12 MEASUREMENT
RANGE
0.5CYC 0.5 to 6.0CYC (in 0.5 CYC steps)
010 to 100ms_ (in 10 ms steps)
001 to 010ms_
6
*
13 Delimiter , 1
14 MEASUREMENT
INTERVAL
00.5CYC 00.5 to 12.0CYC (in 0.5 CYC steps)
0010 to 0200ms_ (in 10 ms steps)
0001 to 0020ms_
7
*
15 Delimiter , 1
16 TIME BEGIN 1 00000.0CYC 00000.0 to 18000.0CYC (in 0.5 CYC steps)
0000000 to 0300000ms_ (in 10 ms steps)
0000000 to 0030000ms_
10
*
17 Delimiter , 1
18 TIME END 1 18000.0CYC 00000.0 to 18000.0CYC (in 0.5 CYC steps)
0000000 to 0300000ms_ (in 10 ms steps)
0000000 to 0030000ms_
10
*
19 Delimiter , 1
20 TIME BEGIN 2 00000.0CYC 00000.0 to 18000.0CYC (in 0.5 CYC steps)
0000000 to 0300000ms_ (in 10 ms steps)
0000000 to 0030000ms_
10
*
21 Delimiter , 1
22 TIME END 2 18000.0CYC 00000.0 to 18000.0CYC (in 0.5 CYC steps)
0000000 to 0300000ms_ (in 10 ms steps)
0000000 to 0030000ms_
10
*
23 Delimiter , 1
24 TIME BEGIN 3 00000.0CYC 00000.0 to 18000.0CYC (in 0.5 CYC steps)
0000000 to 0300000ms_ (in 10 ms steps)
0000000 to 0030000ms_
10
*
25 Delimiter , 1
