MM-400A
12. Data Communication
12-38
Item Display Range Length
16 VOLTAGE RANGE 0 0: 6.00V
1: 20.0V
1
17 Delimiter , 1
18 CURRENT TRIGGER
LEVEL
01 01 to 99 2
19 Delimiter , 1
20 VOLTAGE TRIGGER
LEVEL
01 01 to 99 2
21 Delimiter , 1
22 TOROIDAL COIL 0 0: TIMES 1
1: TIMES 10
1
23 Delimiter , 1
24 END LEVEL 01.5% 01.5 to 15.0% 5
25 Return code [CR] (0x0d) 1
26 Feed code [LF] (0x0a) 1
(Note) When CURRENT is selected for TRIGGER, 0: CYC-AC or 1: ms-AC can be selected
for TIME. When VOLTAGE is for TRIGGER selected, 2: ms-DC, 3: CYC-DC, or 4: SHORT
ms-DC can be selected for TIME.
 Output data common to all schedules (SCH.# 000)
Item
Display
Range
Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
5 Item No. 15 2
6 Delimiter : 1
8 “TRIGGER” to 24 “END LEVEL” in SEAM SETUP  Writing request data for schedule
24 Return code [CR] (0x0d) 1
25 Feed code [LF] (0x0a) 1
