MM-400A
12. Data Communication
12-39
4) COMPARATOR [Item No. 16]
 Writing request data for each schedule 001 to 127
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 001 001 to 127 3
5 Screen code S 1
6 Item No. 16 2
7 Delimiter : 1
8 UPPER 1 (Refer to the upper/lower limit table.) 11
9 Delimiter , 1
10 LOWER 1 (Refer to the upper/lower limit table.) 11
11 Delimiter , 1
12 UPPER 2 (Refer to the upper/lower limit table.) 11
13 Delimiter , 1
14 LOWER 2 (Refer to the upper/lower limit table.) 11
15 Delimiter , 1
16 UPPER 3 (Refer to the upper/lower limit table.) 11
17 Delimiter , 1
18 LOWER 3 (Refer to the upper/lower limit table.) 11
19 Delimiter , 1
20 UPPER 4 (Refer to the upper/lower limit table.) 11
21 Delimiter , 1
22 LOWER 4 (Refer to the upper/lower limit table.) 11
23 Delimiter , 1
24 UPPER 5 (Refer to the upper/lower limit table.) 11
25 Delimiter , 1
26 LOWER 5 (Refer to the upper/lower limit table.) 11
27 Delimiter , 1
28 UPPER 6 (Refer to the upper/lower limit table.) 11
29 Delimiter , 1
30 LOWER 6 (Refer to the upper/lower limit table.) 11
31 Delimiter , 1
32 UPPER 7 (Refer to the upper/lower limit table.) 11
33 Delimiter , 1
34 LOWER 7 (Refer to the upper/lower limit table.) 11
35 Delimiter , 1
36 UPPER 8 (Refer to the upper/lower limit table.) 11
37 Delimiter , 1
