MM-400A
12. Data Communication
12-40
Item Display Range Length
38 LOWER 8 (Refer to the upper/lower limit table.) 11
39 Delimiter , 1
40 UPPER 9 (Refer to the upper/lower limit table.) 11
41 Delimiter , 1
42 LOWER 9 (Refer to the upper/lower limit table.) 11
43 Delimiter , 1
44 UPPER 10 (Refer to the upper/lower limit table.) 11
45 Delimiter , 1
46 LOWER 10 (Refer to the upper/lower limit table.) 11
47 Return code [CR] (0x0d) 1
48 Feed code [LF] (0x0a) 1
 Output data for each schedule 001 to 127
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 001 001 to 127 3
4 Screen code S 1
5 Item No. 16 2
6 Delimiter : 1
8 “UPPER 1” to 46 “LOWER 10” in COMPARATOR  Writing request data
for schedule
46 Return code [CR] (0x0d) 1
47 Feed code [LF] (0x0a) 1
