MM-400A
12. Data Communication
12-41
5) VIEW [Item No. 11]
 Writing request data (SCH.# 000)
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 11 2
7 Delimiter : 1
8 MEASUREMENT
DISPLAY
0 0: 5 ITEMS 1: 10 ITEMS 1
9 Delimiter , 1
10 MEAS 1 00 00 to 34 (Refer to the measurement code
table.)
2
11 Delimiter , 1
12 MEAS 2 00 00 to 34 (Refer to the measurement code
table.)
2
13 Delimiter , 1
14 MEAS 3 00 00 to 34 (Refer to the measurement code
table.)
2
15 Delimiter , 1
16 MEAS 4 00 00 to 34 (Refer to the measurement code
table.)
2
17 Delimiter , 1
18 MEAS 5 00 00 to 34 (Refer to the measurement code
table.)
2
19 Delimiter , 1
20 MEAS 6 00 00 to 34 (Refer to the measurement code
table.)
2
21 Delimiter , 1
22 MEAS 7 00 00 to 34 (Refer to the measurement code
table.)
2
23 Delimiter , 1
24 MEAS 8 00 00 to 34 (Refer to the measurement code
table.)
2
25 Delimiter , 1
26 MEAS 9 00 00 to 34 (Refer to the measurement code
table.)
2
27 Delimiter , 1
28 MEAS 10 00 00 to 34 (Refer to the measurement code
table.)
2
29 Delimiter , 1
30 WAVE 1 0 0 to 7 (Refer to the waveform code table.) 1
