12. Data Communication
12-42
Item Display Range Length
31 Delimiter , 1
32 WAVE 2 0 0 to 7 (Refer to the waveform code table.) 1
33 Delimiter , 1
34 WAVE 3 0 0 to 7 (Refer to the waveform code table.) 1
35 Delimiter , 1
36 WAVE 4 0 0 to 7 (Refer to the waveform code table.) 1
37 Delimiter , 1
38 Waveform display 1 0 0: OFF, 1: ON 1
39 Delimiter , 1
40 Waveform display 2 0 0: OFF, 1: ON 1
41 Delimiter , 1
42 Waveform display 3 0 0: OFF, 1: ON 1
43 Delimiter , 1
44 Waveform display 4 0 0: OFF, 1: ON 1
45 Return code [CR] (0x0d) 1
46 Feed code [LF] (0x0a) 1
 Output data (SCH.# 000)
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
5 Item No. 11 2
6 Delimiter : 1
7 MEASUREMENT
DISPLAY
0 0: 5 ITEMS 1: 10 ITEMS 1
8 Delimiter , 1
9 MEAS 1 00 00 to 34 (Refer to the measurement code
table.)
2
10 Delimiter , 1
11 MEAS 2 00 00 to 34 (Refer to the measurement code
table.)
2
12 Delimiter , 1
13 MEAS 3 00 00 to 34 (Refer to the measurement code
table.)
2
14 Delimiter , 1
15 MEAS 4 00 00 to 34 (Refer to the measurement code
table.)
2
16 Delimiter , 1
17 MEAS 5 00 00 to 34 (Refer to the measurement code
table.)
2
