MM-400A
12. Data Communication
12-45
Item Display Range Length
26 Feed code [LF] (0x0a) 1
 Output data (SCH.# 000)
Item
Display
Range
Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
5 Item No. 14 2
6 Delimiter : 1
7 MODE 0 0: NORMAL
1: SEAM
2: NORMAL TRACE
3: SINGLE TRACE
1
8 Delimiter , 1
9 LANGUAGE 0 0: ENGLISH
1: GERMAN
2: FRENCH
3: SPANISH
4: JAPANESE
5: KOREAN
6: CHINESE
1
10 Delimiter , 1
11 WELD COUNTER PRESET 000000 000000 to 999999 6
12 Delimiter , 1
13 GOOD COUNTER PRESET 000000 000000 to 999999 6
14 Delimiter , 1
15 BRIGHTNESS 01 01 to 10 2
16 Delimiter , 1
17 BRIGHTNESS 0 0: OFF
1: AUTO
1
18 Delimiter , 1
CURRENT
19 SAMPLING INTERVAL 0 0: 20us
1: 50us
2: 100us
3: 200us
1
20 Delimiter , 1
21 CONVERSION COEFFICIENT 100.0mV/kA 100.0 to 250.0mV/kA 10
22 Delimiter , 1
FORCE / EXTERNAL
23 SAMPLING INTERVAL 0 0: 100us
1: 200us
2: 500us
1
