12. Data Communication

12-54

Item Display Range Length

10 Delimiter , 1

11 OUT OF LIMIT

OPERATION

0 0: OFF

1: ON

12 Return code [CR] (0x0d) 1

13 Feed code [LF] (0x0a) 1
