Amada WELD CHECKER MM-400A - Page 274

MM-400A
12. Data Communication
12-53
8) PRINT [Item No. 21]
 Writing request data (SCH.# 000)
Item
Display
Range
Length
1 Start code # 1
2 ID NO. 01 01 to 31 2
3 Write code W 1
4 SCH.# 000 000 3
5 Screen code S 1
6 Item No. 21 2
7 Delimiter : 1
8 ITEM 0 0: OFF
1: MEASUREMENT
2: WAVEFORM
3: CURRENT ALL CYCLE
4: FORCE ALL CYCLE
5: HISTORY
6: HISTORY OUTOF LIM
7: SCHEDULE
8: SCREEN
1
9 Delimiter , 1
10 INTERVAL 0001 0001 to 1000 4
11 Delimiter , 1
12 OUT OF LIMIT
OPERATION
0 0: OFF
1: ON
1
13 Return code [CR] (0x0d) 1
14 Feed code [LF] (0x0a) 1
 Output data (SCH.# 000)
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
5 Item No. 21 2
6 Delimiter : 1
7 ITEM 0 0: OFF
1: MEASUREMENT
2: WAVEFORM
3: CURRENT ALL CYCLE
4: FORCE ALL CYCLE
5: HISTORY
6: HISTORY OUTOF LIM
7: SCHEDULE
8: SCREEN
1
8 Delimiter , 1
9 INTERVAL 0001 0001 to 1000 4
