MM-400A
12. Data Communication
12-56
Item Display Range Length
25 Delimiter , 1
26 SPEED (Note) 0 0: 9600
1: 19200
2: 38400
1
27 Delimiter , 1
28 IP ADDRESS (Note) 000 000 to 255 3
Space 1
000 000 to 255 3
Space 1
000 000 to 255 3
Space 1
000 000 to 255 3
29 Delimiter , 1
30 SUBNET MASK (Note) 000 000 to 255 3
Space 1
000 000 to 255 3
Space 1
000 000 to 255 3
Space 1
000 000 to 255 3
31 Delimiter , 1
32 DEFAULT GATEWAY
(Note)
000 000 to 255 3
Space 1
000 000 to 255 3
Space 1
000 000 to 255 3
Space 1
000 000 to 255 3
33 Delimiter , 1
34 PORT NO. (Note) 1024 1024 to 5000 4
35 Return code [CR] (0x0d) 1
36 Feed code [LF] (0x0a) 1
(Note) Data cannot be changed. Do not make a change while writing data. Input the setting
value as it is.
 Output data (SCH.# 000)
Item Display Range Length
1 Start code ! 1
2 ID NO. 01 01 to 31 2
3 SCH.# 000 000 3
4 Screen code S 1
