MM-400A
12. Data Communication
12-57
Item Display Range Length
5 Item No. 22 2
6 Delimiter : 1
7 ITEM 0 0: OFF
1: MEASUREMENT
2: WAVEFORM
3: CURRENT ALL CYCLE
4: FORCE ALL CYCLE
5: HISTORY
6: HISTORY OUT OF LIM
7: SCHEDULE
8: ENVELOPE
1
8 Delimiter , 1
9 INTERVAL 0001 0001 to 1000 4
10 Delimiter , 1
11 OUT OF LIMIT
OPERATION
0 0: OFF
1: ON
1
12 Delimiter , 1
13 WAVE DECIMATION 0 0: 20us
1: 50us
2: 100us
3: 200us
4: 500us
5: 1000us
1
14 Delimiter , 1
15 UNIT 0 0: OFF
1: ON
1
16 Delimiter , 1
17 DECIMAL POINT
RANGE
0 0: . (period)
1: , (comma)
1
18 Delimiter , 1
19 MODE (Note) 0 0: OFF
1: RS-232C
2: RS-485
3: ETHERNET
1
20 Delimiter , 1
21 MODE (Note) 0 0: ONE WAY
1: TWO WAY
1
22 Delimiter , 1
23 ID NO. 01 01 to 31 2
24 Delimiter , 1
25 SPEED (Note) 0 0: 9600
1: 19200
2: 38400
1
26 Delimiter , 1
