Amada WELD CHECKER MM-400A - Page 295

MM-400A
12. Data Communication
12-74
7) Waveform code table
Item
code
Item name
Measured value
Unit
Display Range Length Display Length
0 CURRENT +0.000
+00.00
+000.0
-9.999 to +9.999
-99.99 to +99.99
-999.9 to +999.9
6 kA 2
1 VOLTAGE +0.00
+00.0
-9.99 to +9.99
-99.9 to +99.9
5 V 1
2 POWER 000.00 000.00 to 300.00 6 kW 2
3 RESISTANCE 000.00 000.00 to 300.00 6 mOhm 4
4 DISPLACEMENT +00.000
+000.00
+0.0000
+00.000
-30.000 to +30.000
-300.00 to +300.00
-3.0000 to +3.0000
-30.000 to +30.000
7 mm
inch
2
4
5 FORCE 00.00
000.0
00000
00.00 to 99.99
000.0 to 999.9
00000 to 09999
5 N
kgf
lbf
1
3
3
6 EXTERNAL +0.000
+00.00
+000.0
+00000
-9.999 to +9.999
-99.99 to +99.99
-999.9 to +999.9
-09999 to +09999
6
V
N
kgf
lbf
degC
degF
Mpa
bar
psi
0
1
1
3
3
4
4
3
3
3
7 No setting - - - - -
