MM-400A
8. Operation Screens
8-24
(1) COMPARATOR MODE
Select % SET or VALUE SET.
% SET: Set the upper value larger and the lower value smaller by a ratio of a
set value from the reference waveform. Set the upper value in the range of +0
to +50% and the lower value in the range of -0 to -50%.
VALUE SET: Set the upper value larger and the lower value smaller by a set
value from the reference waveform.
(2) ENVELOPE INTERVAL
Set the sampling interval for envelope measurement.
You can select from among 20 us, 50 us, 100 us, 200 us, 500 us, and 1000 us.
(Note 1) The settable range of ENVELOPE INTERVAL changes depending on
the selected waveform or the SAMPLING INTERVAL setting. Therefore, make
a setting so as to satisfy all of the followings. If not, “E06: ENVELOPE
ERROR” occurs when editing envelope.
When the waveform type used in the WAVEFORM screen is CURRENT,
VOLTAGE, POWER, or RESIST and the TIME setting in the BASIC SETUP
(1) screen is SHORT ms-DC
CURRENT SAMPLING INTERVAL ENVELOPE INTERVAL
20us 20us, 100us, 200us, 500us, 1000us
50us 50us, 100us, 200us, 500us, 1000us
100us 100us, 200us, 500us, 1000us
When the waveform type used in the WAVEFORM screen is CURRENT,
VOLTAGE, POWER, or RESIST and the TIME setting in the BASIC SETUP
(1) screen is a setting other than SHORT ms-DC
CURRENT SAMPLING INTERVAL
20us、50us 50us, 100us, 200us, 500us, 1000us
100us 100us, 200us, 500us, 1000us
When the waveform type used in the WAVEFORM screen is DISPLACEMENT
CURRENT SAMPLING INTERVAL ENVELOPE INTERVAL
20us、50us 50us, 100us, 200us, 500us, 1000us
100us 100us, 200us, 500us, 1000us
When the waveform type used in the WAVEFORM screen is FORCE or
EXTERNAL and the waveform type used in ENVELOPE#1 and ENVELOPE#2
is CURRENT, VOLTAGE, POWER, RESIST, or DISPLACEMENT
CURRENT SAMPLING INTERVAL
20us、50us 50us, 100us, 200us, 500us, 1000us
100us 100us, 200us, 500us, 1000us
To Next Page
