MM-400A
8. Operation Screens
8-51
(9) FILE NO
When you have selected SCHEDULE for ITEM, FILE NO is displayed.
Set the file number (01 to 10) to read from or write in the schedule data.
“¥sch_set” folder is created, and “¥FileNo_01” to “¥FileNo_10” folders are
created in a lower hierarchy for each file number. Further, the following files
are created in a lower hierarchy for each screen.
Screen Filename
VIEW screen View.csv
ENVELOPE (2) screen Env2.csv
ENVELOPE (3) screen Env3.csv
COMPARATOR screen HiLoComp.csv
PRINT screen Printer.csv
USB screen Usb.csv
BASIC SETUP (1), (2) screens Base12.csv
BASIC SETUP (3) screen Base3.csv
EXTEND SETUP (1), (4), (6) screens Extend146.csv
EXTEND SETUP (2), (3), (5), (7) screens Extend2357.csv
SYSTEM SETUP (1), (2) screens System.csv
EXT INPUT/OUTPUT (1) to (4) screens ExtIO.csv
COMMUNICATION (1), (2) screens Comm.csv
INTERNAL MEMORY screen InternalMem.csv
SEAM SETUP (1), (2) screens Seam12.csv
SEAM SETUP (3) screen Seam3.csv
(10) Function keys
MENU: Touching this displays the MENU screen.
READ: Touching this performs reading schedule setting data or envelope data
from the USB memory. Valid when SCHEDULE or ENVELOPE is selected for
ITEM.
SAVE: Touching this performs writing the item selected for ITEM in the USB
memory. When the USB memory works, “USB” is shown in orange.
