With the "Automatic" setting, the GPS receiver
automatically searches for the correct satellites.
4. If the GPS receiver should send the NMEA 2000
data to the CAN bus,
activate "NMEA 2000 (CAN)".
2
Setting up the Ag-Star receiver
This GPS receiver can be operated with different
configurations. The configurations differ in terms of the
satellite system and correction satellites. The GPS
receiver can be adjusted according to the region and
availability of correction services.
NOTE
With the SBAS correction mode, a signal with higher
accuracy is available as long as the SBAS correction
signal is received.
SBAS includes the correction services EGNOS,
WAAS and MSAS. For more information on this topic,
please consult the operating manual for the satellite
receiver.
Without the correction mode, the received signal is
only corrected by a software. It can take up to 5
minutes for the corrected signal to be available.
If no corrected signal is available, the worked area will
be shown in yellow in the map view. When a corrected
signal is available, the worked area will be shown in
green.
Possible settings:
SBAS GPS
Suitable for North America, Europe and Russia
12 GPS satellites
2 SBAS satellites
GPS / GLONASS
Suitable for North America, Europe and Russia
8 GPS satellites
4 GLONASS satellites
2 SBAS satellites
