1. Drive to the beginning of the row.
2. select .
The start point of the track line is set on the vehicle
position.
3. Drive to the end of the row.
NOTE
The end point of the track line must be at least 15 m
away from the start point.
4. select .
The end point of the track line is set on the vehicle
position. Other track line are added.
3
Creating beds
To create beds, certain track lines can be highlighted.
The highlighted track lines show the row in which the
worked area must be travelled to create a bed of the
desired size. The entered number indicates the rhythm
in which the track lines must be followed. If e.g. a 2 is
entered, every second track line must be followed. In this
way, one track line is always left out and therefore
creates beds of one working width.
CMS-T-00000292-C.1
U | Parallel driving | Creating beds
MG6010-EN-GB | G.1 | 13.12.2018
91
