Operation
b) When incrementing the gate delay, output A delay, output B delay, output C delay, and track gate step is enabled
When using trigger rates less than 87 Hz, the recommended setup is:
Vertical Shift Speed (µsecs)
DH334T (47-10 sensor) 6.5
DH320T (30-11 sensor) 11.3
DH340T (42-10 sensor) 12.9
DH312T (77-00 sensor) 6.5
When using trigger rates greater than 87 Hz, the recommended setup is:
Vertical Shift Speed (µsecs) clean cycle (msecs)
for information only
DH334T (47-10 sensor) 6.5 13.5
DH320T (30-11 sensor) 22.5 (107 Hz maximum) 9.3
DH340T (42-10 sensor) 25.7 16.6
DH312T (77-00 sensor) 25.7 15.4
Note: This mode is not supported in fast external trigger or when using fast kinetics. However IOC and gate step
are available in internal trigger mode.
