Andor Technology New iStar User Manual

Page 21
New iStar ICCD
Introduction to the New iStar
2.3 - CCD PLATFORM SPECIFICATIONS - IMAGING SENSORS
MODEL 312T 334T
Total CCD matrix size (pixels) 512 x 512 1024 x 1024
Fibre optic taper magnication (std)
Ø 18 mm II
1:1
Ø 18 mm II
1:1
Ø 25 mm II
1.5:1
Effective CCD pixel size
24 x 24 μm
100% ll factor
13 x 13 μm
100% ll factor
19.5 x 19.5 μm
100% ll factor
Effective active area 12.3 x 12.3 mm 13.3 x 13.3 mm
Image pixel well depth 320,000 e
-
100,000 e
-
Register well depth 480,000 e
-
150,000 e
-
Read noise (e
-
)
50 kHz
1 MHz
3 MHz
5 MHz
5.4 [7]
10 [14]
16 [20]
24 [50]
5 [7]
8 [12]
14 [18]
20 [50]
Maximum frame and spectral rates
Frame [2 x 2 binning]
Crop mode (frame, 10 rows)
15.8 fps [28.5 fps]
633 fps
4.2 fps [7.3 fps]
333 fps
FVB
Crop mode (spectrum, 10 rows)
291 sps
5,556 sps
145 sps
3,450 sps
Fast Kinetics
4 rows
2 rows
32,150 Hz
55,250 Hz
29,850 Hz
-
Sensitivity
2 to 10 e
-
/count
(software selectable)
1 to 5 e
-
/count
(software selectable)
Linearity Better than 99%
Minimum temperature air cooled
[dark current, e
-
/pixel/sec]
Ø 18 mm II
-30°C [0.4]
Ø 18 mm II
-30°C [0.2]
Ø 25 mm II
-25°C [0.4]
Coolant chiller, coolant @ 10°C, 0.75 l/min
[dark current, e
-
/pixel/sec]
-40°C [0.12] -40°C [0.1] -35°C [0.15]
Note: All specications are typical unless otherwise stated
