Andor Technology New iStar User Manual

Page 41
New iStar ICCD
Solis Software Operation
4.3 - HOT KEYS
Hot keys (or shortcuts) are shown in the following tables, enabling user to work with the system directly from the keyboard.
KEY STROKE(S) DESCRIPTION
F5 Take signal
F6 Autoscale acquisition
Ctrl + B Take background
Ctrl + R Take reference
Esc Abort acquisition
Table 5: Data acquisition Hot Keys
DISPLAY MODE
KEY STROKES DESCRIPTION 2D 3D IMAGE
+ Expand (‘Stretch’) data-axis
ü ü ü
- Contract (‘Shrink’) data-axis
ü ü ü
Ins
If maintain aspect ratio off, expand x-axis.
If maintain aspect ratio on, expand x-axis and y-axis
ü ü ü
Del
If maintain aspect ratio off, contract x-axis.
If maintain aspect ratio on, contract x-axis and y-axis
ü ü ü
/
On image, if maintain aspect ratio off, expand y-axis.
On image, if maintain aspect ratio on, expand x-axis and y-axis.
ü
Home Move cursor furthest left
ü ü ü
End Move cursor furthest right
ü ü ü
PgUp Scroll up through track
ü ü ü
PgDn Scroll down through tracks
ü ü ü
Shift + PgUp Move to next image in series
ü ü ü
Shift + PgDn Move to previous image in series
ü ü ü
Left Arrow Move cursor left
ü ü ü
Right Arrow Move cursor right
ü ü ü
Up Arrow Scroll trace up (on image: move cursor up)
ü ü ü
Down Arrow Scroll trace down (on image: move cursor down)
ü ü ü
Shift + Left Arrow Scroll trace/image left
ü ü ü
Shift + Right Arrow Scroll trace/image right
ü ü ü
Ctrl + Left Arrow Peak search left
ü ü ü
Ctrl + Right Arrow Peak search right
ü ü ü
F7 Toggle Palette
ü ü ü
F8 Reset
ü ü ü
F9 Rescale
ü ü ü
Alt + F9 Toggle Rescale Mode
ü ü ü
Ctrl + F9 Scale to Active (see Section 4 - Displaying Data) section)
ü ü ü
F10 File information
Table 6: Data window Hot Keys
