Andor Technology New iStar - 2.6 GEN 3 INTENSIFIER SPECIFICATIONS

Page 24
New iStar ICCD
PHOTOCATHODE MODEL 18*-63 18*-73 18*-93 18*-A3 18*-C3
Useful aperture Ø18 mm
Input window Glass Glass Glass Glass
MgF
2
+ F/O +
Lumogen
Photocathode type HVS VIH NIR EVS BGT
Peak QE @ room temperature 47.5 25.5 4 40 17
Wavelength range (nm) 280 - 760 280 - 910 380 – 1090 280 - 810 < 200 - 910
Image intensier resolution limit 30 µm 30 µm 30 µm 30 µm 40 µm
Phosphor type
[decay time to 10%]
P43
[2 ms]
Minimum optical gate width (ns)
U (Ultrafast) < 2
F (Fast) < 5
Maximum relative gain > 200
Maximum photocathode repetition rate(with
Intelligate™ OFF)
500 kHz (continuous)
Maximum photocathode repetition rate
(with Intelligate™ ON)
5 kHz (continuous)
Equivalent Background Illuminance (EBI) (e
-
/pix/sec) < 0.1 < 0.3 < 2 < 0.2 < 0.3
2.6 - GEN 3 INTENSIFIER SPECIFICATIONS
