4.2 - MAIN WINDOW
The Main Window is the user ‘entry point’ to the system. The menu options allow the user to either execute specic
functions directly, or launch further windows/dialog boxes to access more comprehensive functionalities. Some menu
options on the Main Window are also accessible through quick-launch buttons, as shown in the table below:
ICON TITLE ICON TITLE ICON TITLE
Open le / program Select sub-image area Image display mode
Print Select autoscale area Change display color palette
Save Reset scale Time stamp settings
Real-time acquisition Rescale data Play kinetic series sequence
Take signal
Acquistion autoscale (live window) Pause kinetic series sequence
Abort acquistion 99 to 1 contrast ratio adjustment Stop kinetic series sequence
Setup acquisition Data histogram display Playback autoscale - Off
Run-time control Region of interest settings Baseline correction
Shutter control File information Periodic table
Spurious noise lter 2D display mode with peak labels Temperature control - Off
Run program 2D display mode Temperature control - On
Command line 3D display mode Help
Table 4: Main window quick-launch buttons
Note: Some menu titles and buttons appear on the Main Window only under certain circumstances as shown on
the next sections.
Note: Icons are grouped by functionalities on dynamic display bars, which can be enabled / disabled through the
View menu.
