Anritsu VNA Master MS2026C Maintenance Manual

1-3 Related Documents General Information
1-2 PN: 10580-00307 Rev. D MS20xxC MM
Frequency Ranges
Standard Accessories
1-3 Related Documents
Other documents are available for the MS2026C, MS2027C, MS2028C, MS2036C, MS2037C, and MS2038C at
the Anritsu web site at: www.anritsu.com
• VNA Master User Guide – part number 10580-00305
• VNA Master Programming Manual – part number 10580-00306
• Vector Network Analyzer Measurement Guide – part number 10580-289
• Spectrum Analyzer Measurement Guide – part number 10580-00244
• VNA Master Technical Data Sheet – part number 11410-00548
Table 1-1. Frequency Range Values
Instrument Frequency Ranges
MS2026C VNA, 5 kHz to 6 GHz, N Connectors
MS2027C VNA, 5 kHz to 15 GHz, N Connectors
MS2028C VNA, 5 kHz to 20 GHz, N Connectors or K Connectors
MS2036C
VNA, 5 kHz to 6 GHz, N Connectors
SPA, 9 kHz to 9 GHz, N Connectors
MS2037C
VNA, 5 kHz to 15 GHz, N Connectors
SPA, 9 kHz to 15 GHz, N Connectors
MS2038C
VNA, 5 kHz to 20 GHz, N Connectors or K Connectors
SPA, 9 kHz to 20 GHz, N Connectors or K Connectors
Table 1-2. Part Numbers for Standard Accessories
Anritsu Part Number Description
10580-00305 MS2026C/MS2027C/MS2028C and MS2036C/MS2037C/MS2038C User Guide
2300-498 Master Software Tools disc
633-75 Rechargeable battery, Lithium-Ion (633-44 can also be used)
40-187-R AC to DC Power Adapter
806-141-R Automotive 12 Volt DC Adapter
3-2000-1498 USB A-mini B Cable, 3 m (10 ft)
2000-1371-R Cat 5 Ethernet Cable
2000-1685-R Soft Carrying Case for MS202xC VNA Master
2000-1686-R Soft Carrying Case for MS203xC VNA Master
