Assembly Removal and Replacement, MS203xC 7-7 Main Menu Keypad Bezel for VNA Master MS203xC
MS20xxC MM PN: 10580-00307 Rev. D 7-5
7-7 Main Menu Keypad Bezel for VNA Master MS203xC
Figure 7-3 shows the Main Menu Keypad Bezel, the location of its locking tabs, and its orientation to the case.
The Main Menu Keys may also be called Function Hard Keys.
1. Main Menu Keypad Bezel Front View
2. Top View
3. Side View
4. Three-Quarter View
5. Locking tab location for the left end of the bezel which goes toward the left side of the case
6. Locking tab location for bezel center
7. Locking tab location for the right end of the bezel which goes toward the right side (handle side) of the case
Figure 7-3. Main Menu Keypad Bezel and Locking Tab Locations for MS203xC
