Battery Information and Replacement 5-4 Battery Pack Removal and Replacement
MS20xxC MM PN: 10580-00307 Rev. D 5-3
5-4 Battery Pack Removal and Replacement
This section provides instructions for the removal and replacing the VNA Master battery pack.
1. With the VNA Master laying flat, face up, on a stable surface, locate the Battery Access Door, as shown
in Figure 5-1, “Battery Access Door Location”.
Note
Many of the procedures in this section are generic, and apply to many similar instruments. Photos
and illustrations used here are representative and may show instruments other than the
MS202xC/MS203xC VNA Master.
1. MS2026C/MS2027C/MS2028C/MS2036C/MS2037C/MS2038C VNA Master
2. Battery Access Door Location at instrument bottom.
Figure 5-1. Battery Access Door Location
1
2
